1 / 6
330 lbs
Load Capacity
59"
Overall Length
24V / 125Ah
Battery
51.2"
Turning Radius
SKU: 777043
5Seconds - Order Picker - 777043 | 330 Lbs Capacity, 118in Lift, 24V/100Ah Gel Battery
- Load Capacity: 3,300 lbs
- Fork Dimensions: 42" L × 8.7–26.8" W × 1.4" Thick
- Battery: 24V / 280Ah
- Battery Type: Lead-Acid
Specifications
Built for the job
MOTORIZED VERTICAL ELEVATION REPLACES ROLLING LADDERS
Engineered to eliminate dangerous warehouse ladder climbing and awkward manual reaching, this fully electric mini order picker lifts an operator and picking cargo smoothly up to a 118" platform height. Designed for high-density retail stockrooms, grocery distribution, and parts picking, it turns strenuous ladder retrieval into fast, push-button vertical access.
ULTRA-SLIM 29.5" PROFILE FOR NARROW AISLE CLEARANCE
With a streamlined 29.5" chassis width and compact 59" overall length, this vehicle effortlessly glides down tight 68.9" storage aisles and slips through standard commercial doorways. Operators maneuver directly between dense racking bays where full-sized forklifts and scissor lifts cannot fit.
DUAL-DRIVE STEERING WITH SHARP 51.2" TURNING RADIUS
A responsive dual-motor steering system provides fluid, zero-scrub turning with a compact 51.2" turning radius. Combined with responsive electric traction that travels up to 5.1 mph, order selectors quickly navigate expansive facilities between pick locations.
MULTI-STAGE AUTOMATIC SAFETY & FOOT SENSORS
Operator safety is reinforced by an active interlock network: dual floorboard foot sensors prevent movement if the operator steps out of position, and two-handed controls require both hands on the console to activate travel or lifting. An automatic safety gate interlock cuts power if opened while elevated, while automated speed logic restricts travel speed as the platform rises.
INTEGRATED CARGO STORAGE TRAY
Equipped with a forward-facing height-adjustable storage tray that holds picking cartons, spare parts, and tools within direct arm's reach. Operators assemble orders or perform facility maintenance directly at height without balancing boxes on ladder rungs.
SEALED 24V POWER & PLUG-IN 110V WALL CHARGING
Powered by a sealed, maintenance-free 24V battery system designed for extended facility shifts without water topping or acid upkeep. The integrated onboard charger plugs straight into any standard 110V commercial wall receptacle, ensuring simple overnight recharging anywhere on site.
Key Features & Benefits:
-
Powered 118" Platform Lift (9.83 ft): Provides safe, stable vertical access to upper storage shelves, eliminating ladder falls and reaching strain.
-
Ultra-Narrow 29.5" Chassis Width: Operates seamlessly inside narrow 68.9" retail aisles, warehouse corridors, and through standard doorways.
-
330 lb Operator & Cargo Capacity: Accommodates operator weight plus parts, tools, or picking cartons on the forward material tray.
-
Dual-Motor Steering System: Delivers agile 51.2" turning radius navigation around tight rack corners and crowded retail displays.
-
Automated High-Elevation Speed Limiting: Automatically throttles drive speed above 19.7" platform elevation for maximum stability at height.
-
Two-Handed Control & Dual Foot Sensors: Deadman floor sensors and dual-hand console switches prevent accidental machine movement.
-
Auto-Locking Platform Safety Gate: Mechanically and electrically locks the compartment to safeguard the operator while elevated.
-
Sealed Maintenance-Free 24V Battery: Delivers clean, quiet electric operation with zero battery watering or acid leakage risks.
-
Built-In 110V Commercial Wall Charger: Connects directly to conventional AC wall outlets without separate charging stations.
-
Manual Emergency Lowering Valve: Features an accessible ground-level bypass valve to ensure safe, controlled platform descent in the event of power loss.
Frequently asked questions
This fully electric mini order picker has a maximum rated capacity of 330 lbs, making it suitable for elevated stock picking, light maintenance, and warehouse operations. Operators must follow the equipment's rated capacity limits for personnel, tools, and materials.
The order picker offers a maximum platform lifting height of 118 inches (9.8 feet), allowing operators to access elevated shelves, warehouse racks, and retail storage areas.
This is a fully electric order picker featuring powered lifting, lowering, steering, and travel. Operators can raise the platform and move the machine using its integrated controls.
Yes. Its compact design features a 29.5-inch overall width, a 51.2-inch turning radius, and a specified operating aisle width of 68.9 inches, making it suitable for many narrow warehouse aisles and retail stockrooms.
