Arrow Manual Pallet Stacker, 777016, | 1,100 Lbs Capacity, Straddle Legs & Adjustable Forks 1 / 5
1,100 lbs Load Capacity
31.5" L × 7.9–29.3" W × 1.9" Thick Fork Dimensions
53.1" Overall Length
63" Max Lifting Height

5Seconds Brand·SKU 777016

Arrow Manual Pallet Stacker, 777016, | 1,100 Lbs Capacity, Straddle Legs & Adjustable Forks

$1,749.99 ea.
  • Load Capacity: 1,100 lbs
  • Fork Dimensions: 31.5" L × 7.9–29.3" W × 1.9" Thick
  • Overall Length: 53.1"
  • Max Lifting Height: 63"
Processing time: ships in 2 business days
Spec sheet Warranty
Available for pick-up

Specifications

Load Capacity 1,100 lbs
Fork Dimensions 31.5" L × 7.9–29.3" W × 1.9" Thick
Overall Length 53.1"
Max Lifting Height 63"
Load Center 19.7"
Turning Radius 48"
Aisle Width 81.3"
Overall Width 60.2"
Inside Fork Width 0.4"–21.5"
Fork Lowered Height 2.8"
Mast Height (Lowered/Extended) 78.3" / 78.3"
Wheel Type Single Wheel
Fork Type Channel Steel Forks
Service Weight 495 lbs


5Seconds Manual Pallet Stacker with Straddle Legs


Standard Mast & Fork Dimensions

  • Compatible with most standard U.S. pallets
  • Enables smooth and stable stacking operations
  • Ideal for diverse warehouse and industrial applications
  • Ensures efficient material handling performance

Fixed forks for stable handling

  • Adapts to different pallet sizes
  • Provides flexibility for various working conditions
  • Expands operational versatility
  • Suitable for multiple warehouse and industrial tasks

Hand and foot lifting operation

  • Supports both hand and foot pedal lifting
  • Reduces operator fatigue during extended use
  • Enhances working comfort and convenience
  • Improves daily productivity and efficiency

Compact design for versatile use

  • Lightweight and space-efficient structure
  • Small turning radius for confined areas
  • Easy and comfortable operation
  • Ideal for warehouses, logistics centers, docks, supermarkets, and manufacturing facilities


 See The 5Seconds Difference

The 5Seconds Arrow Manual Pallet Stacker goes beyond what a standard manual stacker can handle. Its reinforced steel mast, wide straddle legs, and adjustable forks deliver steady support for smooth, controlled lifting and stacking. Rated at 1,100 Load capacity lbs with a 63" lift height, it is well suited for warehouses, production areas, stockrooms, and industrial facilities that require dependable pallet handling and positioning throughout the workday.

Frequently asked questions

The stacker is rated to handle loads up to 1,100 lbs, making it suitable for everyday pallet lifting, stacking, and positioning applications.

The forks can reach a maximum lift height of 63 inches, making the stacker suitable for shelving, workstations, and light-duty stacking applications.

The straddle-leg design allows the legs to position around the pallet, making the unit suitable for closed-bottom pallets and skids that may not work with conventional fixed-leg stackers.

The stacker uses a manual hydraulic lifting system with both hand and foot lifting controls, giving operators flexibility during repeated lifting and positioning tasks.
