1 / 5
3,300 lb
Capacity
48" × 27"
Fork Size
24V / 20Ah
Lithium Battery
7.3" Lift Height
Max Lift
SKU: 555111
Tyson E-1200, Electric Pallet Jack, 555111 | 3300 Lbs
- Load Capacity: 3,300 lbs.
- Fork Size: 48" × 27"
- Fork Length: 48"
- Fork Overall Width: 27"
Specifications
Built for the job
3,300 LB Electric Handling
Electric lift and drive reduce manual labor during pallet movement, helping operators handle repetitive warehouse tasks with greater efficiency.
24V Battery With Fast Swap
The 24V/20Ah lithium battery charges in 3.5 hours, while the quick release design allows a 10 second battery swap to minimize downtime.
Durable Fork Entry Design
The 2.1" thick forks feature sloped tips that help provide smoother entry when positioning the pallet jack beneath pallets.
57.1" Tight Turning Radius
A 57.1" turning radius makes the pallet jack well suited for maneuvering around trucks, containers, and narrower warehouse aisles.
Reinforced Rocker Arm
The one-piece reinforced rocker arm provides a stronger lifting structure designed for durability during regular pallet handling.
Multi-Function Handle Control
The handle puts lift, drive, horn, and safety controls together, keeping essential functions within easy operator reach.
Frequently asked questions
Yes. The quick-release battery design allows the battery to be swapped in approximately 10 seconds, helping reduce downtime when a replacement battery is available.
No. The multi-function handle controls lifting, driving, the horn, and safety functions from the same operating area.
The pallet jack has overload protection, which helps prevent damage associated with lifting an excessive load.
It includes an emergency stop for immediately cutting power when needed and a reverse belly switch designed to support operator safety during reverse movement.
The pallet jack uses polyurethane (PU) wheels, which are designed for quiet operation, shock absorption, and movement without leaving floor marks.
The open chassis provides a clear component layout, making the internal components easier to access when repairs or maintenance are needed.
The product combines a 3,300 lb load capacity with electric lift and drive, a 57.1" turning radius, and a three-wheel configuration. Its strong yet lightweight design supports easy handling and stable load movement, making it a practical choice for regular pallet handling. The electric performance also delivers high value compared with a manual pallet jack.
